Sanchuan LXSF-WC STS Prepaid Water Meter

This STS-compliant prepaid water meter uses secure STS token with encrypted transactions and multi-tier pricing. It supports real-time alerts for low balance, magnetic tampering, and anomalies, automatically shutting off upon overuse. The meter logs monthly and hourly data for over 10 years and features an easily replaceable external battery. With IP68 protection and external valve control, it integrates seamlessly into AMR/AMI systems—ideal for smart-city and residential utility applications.

STS Prepaid Smart Water Meter
STS Prepaid Smart Water Meter

Features of STS Prepaid Smart Water Meter

● DN 15 to 25 Stainless Steel/Cast Iron

● 1L-level electronic precision

● Overdraft and accumulation limits can be configured

● 85 days of daily and 85 months of monthly records

Specification of STS Prepaid Smart Water Meter

GENERAL INFORMATION
TECHNICAL DATA
DIMENSION
LXSF-WC STS Prepaid Water Meter
Medium temperature range°C
0.1 ... +50
Ambient operating temperature

-5 ... +50
Ambient storage temperature

-5 ... +50
Environmental class

O (Outdoors)
Meter body material

Stainless Steel
Nominal pressureMAPbar16
Register material

plastic
Accuracy class

2
Indicating range(m3)

0-99999.99


Nominal DiameterDNmm152025
Model Name

LXSF-WC 15LXSF-WC 20LXSF-WC 25
Permanent flow rateQ3m³/h2.546.3
Minimum flow rateQ1L/h15.6252539.375
Dynamic (Q3/Q1)R
160160160
Overload flow rateQ4m³/h3.12557.875
Transitional flow rateQ2L/h254063
Overall lengthLmm165195225
Connection thread
InchG ¾G1G1 ¼


STS Prepaid Smart Water Meter Dimension
